Product Details:
|
| Model: | A4, Q5, A6 | Year: | 2006-2006, 2000-2003, 1995-1996, 1994-1997, 2008-2012, 2009- |
|---|---|---|---|
| Engine: | 2.0 16V, 2.0, 2.0 16V Quattro | OE NO.: | 06L100860TX |
| Car Fitment: | Audi | Type: | Gas / Petrol Engine |
| Power: | 165kW/4500-6200 Rpm | Displacement: | 1984 |
| Torque: | 350Nm/1500-4200 Rpm | Warranty: | 1 Years |
| Engine Code: | EA888 Three Generations | Car Model: | Audi |
| Condition: | New |
Basic Information:
| Small Short Hair Assembly Number: | 06L 100 860 TX |
| Type code: | CUH CUJ |
| Matching Models: | Audi A4 stepless speed changing / DSG / auto |
| Audi A6 Manual / DSG | |
| Audi Q5 Manual | |
| Volkswagen Fai Ang DSG |
CUH Engine Parameters :
| Engine type | EA888 Three Generations |
| Displacement (mL) | 1984 |
| Intake form | Turbo |
| Cylinder arrangement form | Inline four-cylinder |
| Number of cylinders (units) | 4 |
| Valves per cylinder (units) | 4 |
| compression ratio | 9.6 |
| Valve train | Overhead double camshaft |
| Cylinder diameter (mm) | 82.5 |
| Stroke (mm) | 92.8 |
| Maximum torque | 350Nm/1500-4200 rpm |
| Maximum power | 165kW/4500-6200 rpm |
| Cylinder head material | aluminum alloy |
| Cylinder block material | cast iron |
| Fuel supply mode | "Direct In-Cylinder Injection + MPI" Hybrid Injection |
CUJ Engine Parameters :
| Engine type | EA888 Three Generations |
| Displacement (mL) | 1984 |
| Intake form | Turbo |
| Cylinder arrangement form | Inline four-cylinder |
| Number of cylinders (units) | 4 |
| Valves per cylinder (units) | 4 |
| compression ratio | 9.6 |
| Valve train | Overhead double camshaft |
| Cylinder diameter (mm) | 82.5 |
| Stroke (mm) | 92.8 |
| Maximum torque | 320Nm/1500-3800rpm |
| Maximum power | 132kW/4000-6000 rpm |
| Cylinder head material | aluminum alloy |
| Cylinder block material | cast iron |
| Fuel supply mode | "Direct In-Cylinder Injection + MPI" Hybrid Injection |
1pc/box neutral packaging Export carton/wooden packaging or customized. | Quantity(pieces) | 1 - 10 | 11 - 50 | >50 |
| Lead time (days) | 10 | 15 | To be negotiated |
At present, Our company has five production lines including cylinder block, cylinder head, crankshaft, connecting rod and balance shaft, and assembly lines including cylinder head sub-assembly line, short hair assembly line and long hair assembly line. In addition, the production process also includes perfect cold test, hot test, power measurement and measurement system.
